Everest Sound Labs has some powerful new products on display at the 25th Annual Spring Break Nationals in Daytona Beach FL. Their new ES-D Class D amplifiers are designed by industry veterans with a combined 75 years of mobile electronics experience. The new amplifiers incude 7,500 and 10,000 Watt models designed for extreme SPL competition.
The new ES-D series of Class D amplifiers are designed and built with competitors in mind. All ES-D amplifiers are 1-Ohm stable and are capable of operating on on electrical systems up to 18V for seriously monstrous power output. With more than 9,000W on tap from the big-daddy ES-D7500.1, these amps are sure to take home trophies whenever they compete.
The ES-D3500.1, ES-D5000.1 and ES-D7500.1 are currently available to pre-order from the Everest Sound Labs website. Visit www.everestsoundlabs.com or call 1-386-308-LOUD for more information
Class-D Mono Amplifiers Standard features:
Frequency Response: 15Hz ~ 270Hz
Signal to Noise Ratio: 85dB
Damping Factor: >200
Input Sensitivity: 6V ~ 0.2V
Crossover Slope: 24dB / Oct
Low Pass Filter: 35Hz ~ 250Hz
Subsonic Filter: 10Hz ~ 50Hz
Bass Boost: 0 - 9dB @ 45Hz
Master / Slave Connection (Linked to 2 Ohm)
Phase Shift: 0 ~ 180 degrees
Remote Control
Working Voltage: 8.5V ~ 18V
Amplifier Specifications:
Model: ES-D3500.1
Power @ 4 Ohms at 14.4V - 993 x 1
Power @ 2 Ohms at 14.4V- 1855 x 1
Power @ 1 Ohm at 14.4V - 3509 x 1
Power @ 1 Ohm at ~16V - 3983 x 1
Power @ 1 Ohm at ~18V - 5111 x 1
Working Voltage - 8.5 to 18V
Length 18.9"
Model: ES-D5000.1
Power @ 4 Ohms at 14.4V - 1500 x 1
Power @ 2 Ohms at 14.4V- 2775 x 1
Power @ 1 Ohm at 14.4V - 5000 x 1
Power @ 1 Ohm at ~16V - 6050 x 1
Power @ 1 Ohm at ~18V - 7463 x 1
Working Voltage - 8.5 to 18V
Model: ES-D7500.1
Power @ 4 Ohms at 14.4V - 2217 x 1
Power @ 2 Ohms at 14.4V- 4425 x 1
Power @ 1 Ohm at 14.4V - 7673 x 1
Power @ 1 Ohm at ~16V - 8542 x 1
Power @ 1 Ohm at ~18V - 9034 x 1
Working Voltage - 8.5 to 18V
