The KICKER® DX600.5 5-Channel Amplifier provides reliable, relentless power by using trusted KICKER knowledge and upgraded components for enhancing audio in a high-performance, multimedia system. KICKER DX-Series Amplifiers always exceed rated power, as documented inside the carton. They began shipping during summer.
All KICKER amplifiers now feature FIT™, or Fail-Safe Integration Technology. Alternators, computers and A/V entertainment result in additional noise pulsing through today’s vehicles. FIT utilizes isolated differential inputs, rejecting noise and electrical interference for the quietest operation possible and ultimate audio clarity. FIT also allows KICKER amps to accept output from nearly any factory or aftermarket head unit. FIT comes standard on ALL KICKER amplifiers.
DX-Series Multi-Channel Amplifiers give the listener multiple channels for a choice of installation configurations, including the 5-channel hybrid with a 300-watt sub section. It rates at 75 watts x 4 channels (2 Ohms at 14.4V) with internal electronic crossovers and KICKEQ™ Bass Boost for precision tuning. The high-power, mono channel pulverizes subwoofers uses high-efficiency Class D power, offering a 12dB/octave low-pass electronic crossover variable from 50 to 200 hertz. The sub channel includes a 24dB/octave, high-pass subsonic filter fixed at 25 hertz, and up to +12dB of bass boost centered at 40 hertz. The DX600.5 is remote capable with the ZXRC sold separately.
A muting circuit cancels out additional noise that may surge down the line, so listeners enjoy the cleanest, clearest sound possible. Additionally, a choice of three automatic turn-on modes (remote, DC offset, signal sense) provides ultimate flexibility.
While KICKER amps are always covered by a two-year factory warranty, KICKER will provide an additional one-year extended warranty with the purchase of any KICKER installation kit at the time of the amplifier purchase. Consumers should contact any Authorized KICKER Dealer or log onto www.kicker.com for more information.
KICKER Performance Audio products, a division of Stillwater Designs and Audio, Inc.®, are available for the mobile and home audio aftermarket at authorized dealers worldwide. Consumers needing more information on KICKER or Livin’ Loud® may call the Consumer Information Line at 1-800-256-5425 or visit the brand Web site at www.kicker.com.
Follow KICKER at facebook.com/kickeraudio and twitter.com/kickeraudio.
KICKER DX600.5 5-Channel Amplifier Specifications
Multi-Channel Model (at 14.4V) DX600.5
Power (watts/channel), 2 Ohm stereo 75 x 4
Power (watts/channel), 4 Ohm bridged mono 150 x 2
Class D Power (watts), 2 Ohm mono 300
Remote Bass Control capable Yes
Dimensions (in, mm);
(all models 2-1/4"H x 8-5/16"W x ..."L, 18-1/8,
57mmH x 211mmW x ...mmL) 460
MSRP $449.95
Common to all Models
Frequency Response: 25-20kHz, +0/-1dB
Input Sensitivity: High Level 250mV-10V, Low Level 125mV-5V
Signal-to-Noise Ratio: >95dB, a-weighted, re: rated power
Active Crossover: 12dB/octave, full-range channels variable 50-200Hz, selectable high or all pass
24dB/octave, sub channel high-pass subsonic filter fixed at 25Hz
KICKEQ™ Boost: variable to +12dB, centered @ 40Hz, sub channel only
